D-LINK SWITCH 5-Port Gigabit Unmanaged Desktop Switch DGS-1005A
D-LINK SWITCH 5-Port Gigabit Unmanaged Desktop Switch DGS-1005A
Regular price
25.000 JOD
Regular price
Sale price
25.000 JOD
Quantity
Couldn't load pickup availability
D-Link DGS-1005A – 5-Port Gigabit Unmanaged Desktop Switch
| Category | Details |
|---|---|
| Product Name | D-Link 5-Port Gigabit Unmanaged Desktop Switch |
| Model | DGS-1005A |
| Product Status | Live (F1_v110WW) |
| Key Features | - 5 high-speed Gigabit ports - Compact and fanless design for silent operation - QoS prioritization for smooth data traffic - D-Link Green energy-saving technology - Environmentally friendly and RoHS compliant |
⚡ Performance & Networking
| Specification | Details |
|---|---|
| Ports | 5 × 1000Base-T Gigabit Ethernet |
| Auto MDI/MDIX | Yes |
| Switching Capacity | 10 Gbps |
| Max Packet Forwarding Rate | 7.44 Mpps |
| Forwarding Method | Store-and-forward |
| Jumbo Frame Support | 9,720 Bytes |
| Head-of-Line (HOL) Blocking Prevention | Yes |
| Flow Control | IEEE 802.3x |
| MAC Address Table Size | 4,000 entries |
| Packet Buffer Size | 128 KB |
| Flash Memory Size | 64 KB |
🌱 Energy Efficiency & Power
| Specification | Details |
|---|---|
| Power Input | AC 100–240 V |
| Maximum Power Consumption | 3.90 W |
| Standby Power Consumption | 0.6 W |
| Maximum Heat Dissipation | 13.299 BTU/h |
| Power Saving Features | - By cable length - By link status - Energy Efficient Ethernet (EEE) |
| MTBF | 1,152,221 hours |
| Fan | Fanless (silent operation) |
🌍 Environmental Conditions
| Specification | Details |
|---|---|
| Operating Temperature | 0 °C to 40 °C |
| Storage Temperature | –10 °C to 70 °C |
| Operating Humidity | 0%–95% RH |
| Storage Humidity | 0%–95% RH |
| Operating Altitude | Up to 2000 m |
🔒 Safety & Compliance
| Specification | Details |
|---|---|
| Air Discharge Protection | 8 kV |
| Surge/Lightning Protection | AC Power Inlet: 1 kV Ethernet Ports: 1 kV |
| Compliance | - Energy Star Level V - CEC & MEPS - RoHS 6 - WEEE Directive |
📦 Physical Specifications
| Specification | Details |
|---|---|
| Dimensions (W × D × H) | 91 × 73 × 22 mm |
| Weight | 800 g |
| Design | Compact desktop housing, fanless |
📝 Additional Notes
Actual performance may vary depending on network conditions, device compatibility, cabling, and environmental factors. Specifications are subject to change without notice.
